Automatic Centerless Lathe Peeling Machine For Bar

FOB Reference Price:Get Latest Price
$125,000.00 - $145,000.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Horizontal
CNC or Not:
CNC, CNC
Automatic Grade:
Automatic
Place of Origin:
Shandong, China (Mainland)
Brand Name:
DLDT
Model Number:
WXC40S
Voltage:
Customer's Requirement
Dimension(L*W*H):
Depend
Certification:
CE ISO
Peeling Diameter:
6-40mm
Length Required:
≥1400mm
Diameter Cutting Depth:
0.5-2.0mm
Diameter Tolerance:
IT≤9
Surface Roughness:
μ≤6.3 μm
Total Capacity:
55KW
Model:
Wxc40s
Weight:
5500KGS
After-sales Service Provided:
Overseas third-party support available
Power(W):
55KW
Max. Swing Diameter:
800mm
Supply Ability
Supply Ability:
20000 Piece/Pieces per Year
Packaging & Delivery
Packaging Details
Wood Case With Waterproof Plastic
Port
Dalian
Lead Time :
About 60-90 days
Product Description

Automatic Centerless Lathe Peeling Machine For Bar

Introduction of Centerless Lathe
Series WXC Centerless Lathe is a high efficiency lathe which is specialized in rough processing and finishing of the surface of slender shaft. Not only quickly remove surface hardened layer, cracks and other defects, but also can get high precision.
During processing, the bar itself doesn’t rotate. The cutter head drives the tools rotating at high speed to peeling the surface of the bar. At the same time, after peeling, the bar keeps walking straight ahead. The machine suits for processing the bars and wire rods.Series WXC Centerless Lathe includes semi-automatic hydraulic type and CNC type.

Features of Centerless Lathe

Following advantage compared with ordinary lathe:
1.When processing over-length bar,Centerless Lathe has incomparable advantages.Ordinary lathe is good at processing short bar.But there is great restriction for processing long shaft.In theory,Centerless Lathe can process the bar of infinite length.
2. Centerless Lathe is not only processing bar, also wire rod. Including from wire rod to wire rod and from wire rod to bar.That the ordinary lathe can’t do it.
3. Processing speed 1~12m/min, the working efficiency of Centerless Lathe is dozens of times of the ordinary lathe.
4.High precision, after peeling, tolerance of diameter reach≤IT9, surface roughness Ra≤6.3μm. But after straightening, Ra≤0.8μm.

Detailed Images

Introduction of Composition

1. Main machine consists of the bed, main bearings, air/oil lubrication system, front-clamping pinch feeding and rear-clamping extracting, front guide and middle-rear guide system, main driving system etc.

2. Air/oil lubrication system is specially designed to solve the lubrication of main shaft bearings with high speed rotation. It’s composed of pump, oil and air distribution block and air processing components.

3. Cutting liquid circulation cooling system consist of recycle water pump. Pipeline, nozzle etc.

4. High pressure water pump takes the cutting liquid cooled from reservoir through pipeline transporting the near to the nozzle of cutter head, until spraying on the tools and scraps. Then take away most the cutting heat and enter into chip conveyor mouth of at the bottom of cutter head, through the pipeline reflow reservoir for cooling.

5. Chip conveyor is provided by our supplier. The scraps through chip conveyor mouth to be taken to the chain plate and driving belt move with the scraps. Finally, the scraps are centralized collection.

6. Hydraulic system consists of pump set of motor, all kinds of control valves, hydraulic oil tank, hydraulic pipeline etc. Through controlling the cylinders of front clamping pinch feeding and rear clamping extracting to realize clamping and loosening for the bar.

7.Electrical system includes power supply system and control system, by 1 power distribution cabinet and 1 button station integrated operation, implement pinch before and after the main transmission system, feeding system, cooling system, hydraulic system, the electrical control of chip conveyor and auxiliary machine.

Our Service

1. Free quality guarantee period for 12 months
2. Free long-term technical support
3. Free train for buyer's operator in our factoty
4. Fast response service within 24 hours
5. Our engineers can offer overseas service, including guiding intallation, commissioning, training, etc.

FAQ

1 Q:Do you accept the sample order?
A: Yes, we accept the sample order. If you order the small piece in stock, it is free.
While the buyer needs burden the freight to your destination.

2 Q: How long is your delivery time?
A: Usually 45 to 60 days after your down payment, it also according to the material requirement
and the quantity you ordered.

3 Q: What is your terms of payment.
A: Payment less or equal 10000USD,100% T/T in advance. Payment more than 1000USD,
30% T/T in advance, balance before shippment. Also accept the L/C at sight.

5.Q:What is your working time?
A:Monday-Friday : 8:00AM-17:00PM (Beijing time, GMT+08.00)
While by whatsapp you can contact me anytime if I am awake up.

6.Are you manufacture or trading company?
A:We are trading company,while we are the general agent of our partner factory.
1.We get the price must cheaper than any end user.
2.More prefessional than factory about the knowledge of products.
3.More flexiable trading form. Small order acceptance.
4.Quality objection solve within 7 days when client inform us.
5.Our aim is the quality is first.
